Rigging procedures
Mounting a truss clamp on Syva Wall
type of deployment own
rigging accessories Syva Wall
tools wrench
additional material Truss clamp
M10 bolt with thread-locking device or sealant
min number of operators 1
About this task
Syva Wall can be tted with a truss clamp to mount Syva on a truss bridge.
Exploded view
Follow the clamp manufacturer's recommendations on maximum torque.
Mount the truss clamp on the base using one of the two M10 holes.
Refer to Wall-mounting Syva (p.44) for subsequent steps.
Syva owner's manual (EN) version 1.0 51
