L-Acoustics S Series User Manual

System components
System components
Loudspeaker enclosures
Syva 2-way-passive enclosure: 6 x 5'' LF + 3 x 1.75'' HF diaphragm
Syva Low High power low frequency subwoofer: 2 x 12'' LF
Syva Sub Infra low frequency subwoofer: 1 x 12'' LF
Powering and driving system
LA2Xi / LA4X /
LA7.16i / LA12X
Amplied controller with DSP, preset library and networking capabilities
Refer to the LA2Xi / LA4X / LA7.16i / LA12X owner's manual for operating instructions.
Rack
LA-RAK II AVB Touring rack containing three LA12X, LA-POWER II for power distribution, LA-PANEL II for audio
and network distribution, and two LS10 for AVB distribution
Cables
SP cables SpeakON loudspeaker cables (4-point, 4 mm² gauge)
Come in different sizes: SP.7 (0.7 m / 2.3 ft), SP5 (5 m / 16.4 ft), SP10 (10 m / 32.8 ft), and
SP25 (25 m / 82 ft)
SP-Y1 Breakout cable for two passive enclosures (2.5 mm² gauge)
4-point speakON to 2 × 2-point speakON, provided with a CC4FP adapter
DO cables PA-COM loudspeaker cables (8-point, 4 mm² gauge)
Come in different sizes: DO.7 (0.7 m / 2.3 ft), DO.10 (10 m / 32.8 ft), and DO.25 (25 m /
82 ft)
DOSUB-LA8 Breakout cable for four passive enclosures (4 mm² gauge)
8-point PA-COM to 4 × 2-point speakON
DOFILL-LA8 Breakout cable for two 2-way active enclosures (4 mm² gauge)
8-point PA-COM to 2 × 4-point speakON
DO3WFILL Breakout cable for one 2-way active enclosure and two passive enclosures (4 mm² gauge)
8-point PA-COM to 1 × 4-point speakON and 2 × 2-point speakON
custom 2-point
speakON cable
2-point speakON cable (2.5 mm² gauge) to bare wire cable
This cable needs to be custom made.
2 × 2.5 mm² cable speaker cable with bare wire endings
Adapt the cable length to the installation.
Information about the connection of the enclosures to the LA amplied controllers is given in
this document.
Refer to the LA2Xi / LA4X / LA7.16i / LA12X owner's manual for detailed instructions about the whole cabling
scheme, including modulation cables and network.
Rigging elements
Syva Wall Wall-mount for Syva
Syva owner's manual (EN) version 1.0 9
