Rigging procedures
Rigging procedures
Wall-mounting Syva
type of deployment wall-mount
rigging accessories Syva Wall
tools torque screwdriver
T30 Torx bit
additional material 2 x M6 screws and anchors (depending on wall material)
min number of operators 1
Secondary safety
Secure a DIN-580 eye bolt to the dedicated insert on the enclosure to implement a secondary safety.
The speakON connector is only accessible if Syva Wall is used with a wedge.
Syva Wall can be mounted on a truss bridge.
Refer to Mounting a truss clamp on Syva Wall (p.51).
Assembly
Procedure
1. Remove the safety pin and divide Syva Wall into base and bracket.
base
bracket
44 Syva owner's manual (EN) version 1.0
