L.R. Baggs Active Di User Manual

TOP FEATURES
A. INSTRUMENT INPUT
The ¼” input is an unbalanced (mono), all-discrete
input. Plugging into the input will activate the Active DI,
therefore, unplugging will turn the system o.
B. PAD
The pad switch is used to adjust the XLR output to 0dB
(no change), -10dB, or -20dB. Adjust this depending on
the needs of the PA or amplier.
B
D
CF
H
G
E
A

L.R. Baggs Active Di Specifications

General

Brand	L.R. Baggs
Model	Active Di
Category	Music Pedal
Language	English
