TOP VIEW (continued)
D. Volume
This is a Master Volume that functions independently from the AcousticLive app. This will control the levels
of both the ¼” out and the XLR out.
E. Pad
The pad switch is used to attenuate the input by 0dB (no change), -3dB, -6dB, or -9dB. Adjust this depending
on the output of your pickup. A dot in the lower right hand corner of the display will light up to show if
clipping is occurring. If this occurs, select a lower setting on the pad for better performance.
F. Next
This footswitch is used to quickly scroll through the list of stored presets, automatically skipping any empty
slots. Press the footswitch once to activate the next preset.
G. Mute (and Bypass)
This footswitch is used to mute the signal from both the ¼” out and the XLR out. A solid light will appear
above the footswitch when the Mute is engaged. Additionally, this footswitch can be held to engage a
Bypass function. Visual indicators of the Bypass function include a ashing light above the footswitch and
BYP on the digital display.
E
F
D
G
