L.R. Baggs Voiceprint D.I. User Manual

SPECIFICATIONS
1/4” INPUT
Input Impedance: 2.2 Megohms
Input Pad: 0dB, -3dB, -6dB, -9dB
Input Level: -25dBv to +6.24dBv (.053Vrms to 2.05Vrms)
EFFECTS LOOPS
Send Level: 0dBv (0.707Vrms)
Output Impedance: 600 Ohms
Return Level: 5.2dBv (1.414Vrms) Maximum before clipping
Input Impedance: 600 Kohms
DI OUT
Output Level: 0dBv (0.707Vrms) Balanced
Output Impedance: 600 Ohms
LINE OUT
Output Level: 0dBv (0.707Vrms) Balanced
Output Impedance: 600 Ohms
POWER
DC Power Consumption: 4.5W Max @ 9V
Voltage Range: 9VDC – 16VDC
Power Supply: 9VDC with 500mA minimum (included)
*IMPORTANT: polarity Pos (+) on outside, Gnd (-) on center
Signal to Noise: 90dB, unweighted
DIGITAL
A/D and D/A Conversion: 24-bit, 96kHz
DSP: 32-bit oating point DSP processing
Bluetooth Version: V4.2 up to 5.0
iPhone Version: iPhone 6 and later
PHYSICAL CHARACTERISTICS
1.25 lbs, 5” Width x 4.75” Depth x 2.5” Height
These specications may change without notice.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired operation.
Features exclusive to the AcousticLive app:
Voiceprint settings
Anti•FB settings
EQ settings
Preset library
PRODUCT REGISTRATION
Register the Voiceprint DI online at:
lrbaggs.com/register
LIMITED WARRANTY
L.R. Baggs warrants to the using purchaser that this product shall be free of defects in workmanship and
materials under normal and proper use for a period of one year. If you experience problems with the
Voiceprint DI, please contact your dealer.
To learn more about this product, please visit:
lrbaggs.com/voiceprint

L.R. Baggs Voiceprint D.I. Specifications

Input Specifications

input impedance	2.2 Megohms
input pad	0dB, -3dB, -6dB, -9dB
input level	-25dBv to +6.24dBv (.053Vrms to 2.05Vrms)

Effects Loops Specifications

send level	0dBv (0.707Vrms)
output impedance	600 Ohms
return level	5.2dBv (1.414Vrms) Maximum before clipping
input impedance	600 Kohms

Output Specifications

di out output level	0dBv (0.707Vrms) Balanced
di out output impedance	600 Ohms
line out output level	0dBv (0.707Vrms) Balanced
line out output impedance	600 Ohms

Power

dc power consumption	4.5W Max @ 9V
voltage range	9VDC – 16VDC
power supply	9VDC with 500mA minimum (included)
signal to noise	90dB, unweighted

Digital Specifications

a/d and d/a conversion	24-bit, 96kHz
dsp	32-bit floating point DSP processing
bluetooth version	V4.2 up to 5.0
iphone version	iPhone 6 and later

Physical Characteristics

weight	1.25 lbs
width	5 inches
depth	4.75 inches
height	2.5 inches
