Water pressure  indicates the boiler pressure: 1.3 ÷ 1.4 bar
(18 ÷ 20 psi)
Unit temperature  indicates the unit temperature, from 70 to
110 ° C and from 158 to 230 ° F
Stop steam temperature  indicates the automatic stop steam
temperature (Turbosteam). Can be set between a minimum of 50
and a maximum of 85° C (122  185 ° F).
MEASURING UNIT  includes 2 sub-menus
Temperature  can be set to °C Celsius centigrade or °F Fahrenheit
degrees.
Pressure  can be set to bar or psi.
N. grounds  refers to number of grounds, from 0 (external
container) to 50.
Piston diameter  various piston diameters can be set. 001 =
Ø 35mm; 002 = Ø 44 mm; 003 = Ø 50 mm.
REGENERATION - includes the parameters for the softner
regeneration: liters of resin (da 0,1l a 25l), hardness (da 0 a 45 °F)
6. Configuration menu
Þ CONFIGURATION
Water press. 1,4 bar
Group temp. 070°C
T stop steam 075°C
MEASUREMENT UNITS
N° ground 030
Piston diamet. 002
SOFTNER REGENER.
+
u
Customer programming  YES/ NO
Payment system  permits configuration of payment system,
when connected.
WASHING OPTIONS
Includes 2 parameters for configuring automatic washing (10 ÷
99 OFF) and milk block (YES  NO)
Standard data  loads standard data. YES/NO
Archive reset  zeros the error log stored on the machine: YES/
NO
DATA IN/OUT  contains three entries:
Key  indicates the key number from 0 to 60.
Data IN transfer from smart card to machine. OUT transfer from
machine to smart card.
TX/RX  to start data transfer
HARDWARE SETUP - Includes 5 entries for setting power and voltage
parameters for the motor (disabled):
Current threshold  maximum current setting for coffee pressing.
There is just one parameter for the whole machine, from 001 to 009.
Recommended setting: 005.
PWM threshold  maximum motor voltage for the rise phase. It is a
fixed setting and there is just one parameter for the whole machine,
from 001 to 255. Recommended setting: 240.
PWM compression  voltage applied to the motor for the return of
the chamber after compression. It is a fixed setting and there is just
one parameter for the whole machine, from 001 to 244. Recommended
setting: 140.
Compensation current: power supplied to the motor during
dispensing to prevent return of the unit (reversibility), from 00 to 09.
Recommended setting: 06.
Washing threshold  maximum current allowed for the motor during
the washing phase.
Þ CONFIGURAZIONE
HARDWARE SETUP
Þ CONFIGURATION
Custumer prog. NO
Paym. system OFF
WASHING OPTIONS
Standard data NO
Archive reset NO
DATA IN/OUT
MAINTENANCE
+
u
-
u
MANUTENZIONE - comprende 5 parametri per l'impostazione dei
parametri di manutenzione:
Max cycles - the number of cycles initially set: 40,000.
Max days - the number of days initially set: 185.
N° cycles - the number of cycles remaining before the next
maintenance session.
N° days - the number of days remaining before the next
maintenance session.
Reset - options are:
NO, countdown of cycles and days remaining
before the next maintenance session.
ON, the settings for number of cycles (40,000)
and remaining days (185) are reset
OFF, all controls for programmed maintenance
are disabled, and the N. cycles and N. days
counters are zeroed.
-
