Initial Setup
Outdoor Sensor
TX141TH-BV2
Sensor Battery
Compartment
2 “AA” LR6 Batteries
Sensor
Battery
Cover
LED
Battery
Compartment
3 “AAA” LR3 Batteries
Bottom View
AAA
TX
Button
Page | 2
AAA
AA
AA
Step 1: Insert the 5 volt AC adapter (included) into the wall outlet then into
the weather station.
Step 2 (optional): Insert 3 new “AAA” LR3 Alkaline batteries (not included ) into
the weather station to maintain time during power loss.
Note: Check that battery polarity is correct.
Step 3: Insert 2 new “AA” LR6 batteries (not included) into the TX141TH-
outdoor sensor. The red LED will flash during transmission.
BV2
Note: Check that battery polarity is correct.
Step 4: After 5 minutes, place the sensor outside.
If the outdoor temp is not displayed after three minutes, press and release the
TX/RCC button to search for (RECHERCHE TX/RCC) sensor. Press the TX button
on the sensor to send a signal.
AC/DC
Adapter Jack
AA
AA
AAA
To Next Page
