C 68:4
Level Load Rated power Line Current *2) Watt *1) Thermal Dissipation
115 VA C 230 VAC In Out Dissipated BTU/hr kCal/hr
Standby with remote power off via NomadLink 0 0 0 0 0
Powered on, idling. 133 0 133 454 114
Amp (I) Watt
Pink noise (1/8
rated power)
8 Ω / Ch. 1200 x 4
16.0 8.0 1123 600 523 1784 450
16 Ω / Bridged 2400 x 2
4 Ω / Ch. 1700 x 4
22.4 11. 2 1578 850 728 2484 626
8 Ω / Bridged 3400 x 2
2 Ω / Ch. 1200 x 4
21.2 10.6 1378 600 778 2655 669
4 Ω / Bridged 2400 x 2
100 V / Ch. 1600 x 4
21.0 10.5 1463 800 663 2262 570
200 V / Bridged 3200 x 2
Pink noise
(max power)
*3)
8 Ω / Ch. 1200 x 4
30.0 16.0 2235 / 2384 1472 / 1571 762 / 813 2601 / 2778 655 / 700
16 Ω / Bridged 2400 x 2
4 Ω / Ch. 1700 x 4
30.0 16.0 2085 / 2224 1237 / 1320 848 / 904 2894 / 3089 729 / 778
8 Ω / Bridged 3400 x 2
2 Ω / Ch. 1200 x 4
30.0 16.0 1957 / 2087 1023 / 1091 934 / 996 3188 / 3399 803 / 856
4 Ω / Bridged 2400 x 2
100 V / Ch. 1600 x 4
30.0 16.0 2208 / 2355 1356 / 1446 852 / 909 2908 / 3102 733 / 782
200 V / Bridged 3200 x 2
Mains connector, 230 V CE version 16 A, CEE7
Mains connector, 115 V ETL version 20 A / 5-20P
*1) The ampli er’s PSU operates as a non-resistive load, so the calculation “Volts x Amps = Watts” would not be correct. Instead, measured and
speci ed here is what is known as the “Active Power” in the ampli er providing useful, real-world values of power consumption and heat dissipation.
*2) Current draw gures measured at 230 V. 115 V gures are 230 V gures multiplied by two.
*3) Figures measured at maximum sustainable power without tripping the mains fuse. Listed separately for 30 A/115 V and 16 A/230 V operation. Note
that the max. power condition is very extreme and will not occur during normal operation. Also note that the mains breaker will not be tripped even if
operation is momentarily in excess of max. ratings.
