C 16:4
Level Load Rated power Line Current *2) Watt *1) Thermal Dissipation
115 VA C 230 VAC In Out Dissipated BTU/hr kCal/hr
Standby with remote power off via NomadLink 0 0 0 0 0
Powered on, idling. 129 0 129 440 111
Amp (I) Watt
Pink noise (1/8
rated power)
8 Ω / Ch. 400 x 4
8.6 4.3 526 200 326 1112 280
16 Ω / Bridged 800 x 2
4 Ω / Ch. 300 x 4
8.2 4.1 485 150 335 1143 288
8 Ω / Bridged 600 x 2
2 Ω / Ch. n.r.
*4)
4 Ω / Bridged n.r.
*4)
100V / Ch. 400 x 4
7.6 3.8 463 200 263 897 226
200V / Bridged 800 x 2
Pink noise
(max power)
*3)
8 Ω / Ch. 400 x 4
16.2 8.1 1046 533 513 1749 441
16 Ω / Bridged 800 x 2
4 Ω / Ch. 300 x 4
15.2 7.6 953 400 553 1887 475
8 Ω / Bridged 600 x 2
2 Ω / Ch. n.r.
*4)
4 Ω / Bridged n.r.
*4)
100 V / Ch. 400 x 4
14.4 7. 2 944 533 411 1401 353
200 V / Bridged 800 x 2
Mains connector, 230 V CE version 16 A, CEE7
Mains connector, 115 V ETL version 15 A / 5-15P
*1) The ampli er’s PSU operates as a non-resistive load, so the calculation “Volts x Amps = Watts” would not be correct. Instead, measured and
speci ed here is what is known as the “Active Power” in the ampli er providing useful, real-world values of power consumption and heat dissipation.
*2) Current draw gures measured at 230 V. 115 V gures are 230 V gures multiplied by two.
*3) Figures measured at maximum sustainable power without tripping the mains fuse. Listed separately for 30 A/115 V and 16 A/230 V operation.
Note that the max. power condition is very extreme and will not occur during normal operation. Also note that the mains breaker will not be tripped
even if operation is momentarily in excess of max. ratings.
*4) Regarding n.r. (not recommended) notes: The ampli er will be fully operational in bridge-mode into 2 or 4 ohms, but due to physical
constraints in the construction, the max. output power will not be signi canty higher than running individual channels and therefore this mode of
operation is not recommended.
