4
1) INDICATIVE DESCRIPTION OF THE SYSTEM
EXTERNAL RADAR
INTERNAL RADAR
OPENING COMMAND
PROGRAM SELECTOR
CLOSING SAFETY SENSOR
OPENING SAFETY SENSOR
AUTOMATION NEXT
ELECTRIC LOCK
FLOOR STOP
2) TECHNICAL DATA
AUTOMATION MODEL NEXT 75 NEXT 150 NEXT 120S
POWER SUPPLY 115/230~, 50/60Hz
POWER 40W 50W 50W
DIMENSIONS OF THE AUTOMATION (L x H x D) 420 x 60 x 74mm 420 x 60 x 74mm 520 x 60 x 74mm
FREQUENCY OF USE continuous
OPERATING TEMPERATURE -15° C +50°C
ELECTRIC MOTOR brushless 24Vdc
POWER SUPPLY OF EXTERNAL ACCESSORIES 24 Vdc, 1A
STAND-BY CONSUMPTION 5 W
EQUIPMENT CLASS
class II
SOUND PRESSURE EMISSION
NOTE:
The grey part indicates the
monitoring zone of radars
and sensors.
