Ultimate-cell Stackable Shaking Incubator V2017.2
21
“Shaking Flask” Status:
The illustration of “flask” indicates the status of the unit; the flask
remains still when unit is stopped; or keeps swinging when it’s shaking.
Photosynthetic Lighting Switch
Press it to enable or disable the photosynthetic LED lighting function.
Red Light Indicator
The indicator lit when the red light is on, with display of current lighting
output value in percentage.
Blue Light Indicator
The indicator lit when the blue light is on, with display of current lighting
output value in percentage.
“Control Mode” Status:
This box indicates the status of the current control mode, fixed value
mode or programmable mode.
If it is controlled under Fixed Value mode, no display.
If it is controlled under Programmable mode, it displays the current
segment number and remaining cycle times.
“Speed” Display:
It displays the current operating speed in rpm.
“Temperature” Display:
It displays the current operating temperature in °C.
“Humidity” Display:
It displays the current operating relative humidity in RH%.
“Time” Display:
It displays current accumulative running time in minutes.
“CO
2
” Display:
It displays the current operating CO
2
concentration in %
Special Remind!
Under programmable mode, the “SEG” box shows as followings,
P”m”/L’’n”,
m: Current segment No.
n: Remaining cycle times.
