4.2.HELM STATIONS
4
30
4.3.STEERING SYSTEM
4.3.1
.General description
The steering system is hydraulic.
ATTENTION
Never use the helm actuator as a starboard
forepeak access step.
ADVICE-RECOMMENDATIONS
It is recommended to always use the oil
provided by the supplier or, at the very
least, an oil with a viscosity of ISO 22.
431 2 5 6 7
7 - Engine display (option).
8 - Bow thruster control (option).
9 - Port engine starter panel.
10 - Engine controls.
11 - Starboard engine starter panel.
1 - 16" screen for electronics (option).
2 - Chain meter (option).
3 - Wheel steering system.
4 - 6-key panel.
5 - Screen/repeater for electronics (option).
6 - Screen/repeater for electronics (option).
8 9 10 11
