4.6.FRESH WATER SYSTEM
4.6.1
.Fresh water circuit: 2 x 175 L + 12 X 240 L
FRESH WATER 175 L FRESH WATER 175 L
GREY WATER 120 L
(optional)
GREY WATER 120 L
(optional)
FRESH WATER
240 L
FRESH WATER
240 L
BLACK WATER 155 L
BLACK WATER 85 L
BLACK WATER 155 L
VERSION 4 HEAD/SHOWER COMPARTMENTSVERSION 3 HEAD/SHOWER COMPARTMENTS
ATTENTION
The tanks may contain zones of leftovers
that the pumps cannot reach due to the
boat's trim or the design of suction tappings.
You are advised to maintain a reserve.
The LAGOON 51 is equipped with four rotomoulded food-
grade plastic fresh water tanks of 175 and 240 litres each,
under the passageway floors.
There is no direct transfer between the two tanks.
If the boat is equipped with a desalinator (option), a main
valve allows to choose which tank is fed by the desalinator.
The selection of freshwater tanks feed from the desalinator
is under the port aft cabin floors.
