ADVICE-RECOMMENDATIONS
Hydraulic fluid must be non-flammable or have
a flash point of at least 157 °C.
4.3.4.Emergency system
Boats fitted with a steering wheel have an emergency tiller. Make sure this tiller can be easily reached at all times.
The emergency tiller is stored in the port engine hold, and must remain easily accessible at all times.
- To deploy the tiller:
- Use a winch handle to unscrew one of the emergency tiller covers found on one of the aft skirts.
- Fit the emergency tiller into the rudder shaft, making sure that it is pushed down properly.
- Place the actuator valve in the engine hold on the relevant side in the by-pass position. This isolates the rudder from the
helm system.
3
4
5
1 - Steering actuator.
2 - Steering actuator valve.
3 - Emergency tiller.
4 - Screw + nut for tiller.
5 - Actuator valve in by-pass position.
2
1
