4.4.3.Emergency startup
If the engine batteries are not available, a coupling system of the port and starboard 12 V starting batteries is available (in the
engine compartment port side).
To select the battery coupling:
- Turn on (ON) the coupling circuit-breaker in the port compartment and the port or starboard engine battery circuit-breaker,
while turning off the defective battery (OFF position).
- Start the engines, both port and starboard sides.
- Once both engines have started, switch off (OFF position) the coupling cut-out.
ENGINE COUPLING BATTERY CUT-OUT
PORT ENGINE BATTERY CUT-OUT
STARBOARD ENGINE BATTERY CUT-OUT
STARBOARD ENGINE
PORT ENGINE
PORT LOAD SPLITTER
STARBOARD LOAD SPLITTER
