EQUIPMENT
39
12 V CIRCUIT - US
Lead acid battery bank
420 Ah / 12 V DC
840 Ah / 12 V DC (option)
Engine alternator
Engine room ventilation outlets
Audible alarm for the bilge pumping
system
Relay 70 A
STOVE AND GAS HOB
Eqmt. LIGHT
Eqmt. COLD
Eqmt. Electronic
POWER BUS DC - 12 V
INVERTER
DC / AC
Main circuit cut-off
VIATEMIS 250 Ah
3 x AGM 12 V 140 Ah
+
Extra option
3 x AGM 12 V 140 Ah
PERMANENT BUS DC - 12 V
