Lagoon 51 - Page 46

46
4
46
220 V CIRCUIT - EUROPE
Lead acid battery bank
420 Ah / 12 V DC
840 Ah / 12 V DC (option)
Engine alternator
Chargers
Engine room ventilation outlets
Audible alarm for the bilge pumping system
Charger CRISTEC 60 A
OR 100 A with Option for extra batteries
Source selector switch
75 A
Source selector switch
75 A
Automatic priority
CONVERT or SHORE
SUPPLY PC
Comfort and technical sockets
HiFi - VIDEO
CHARGERS
MISC AC EQPMT
AIR CON / AIR HEATERS
Main circuit cut-off
VIATEMIS 250
Ah
Option Convert
MASTERVOLT 2 kVA 230 V
Option GE
12.8KW 230V 50HZ
Option AC 220 V
32 A
Option AIR CON
32 A
3 x AGM 12 V 140 Ah
+
Extra option
3 x AGM 12 V 140 Ah
PERMANENT BUS DC - 12 V
STOVE AND GAS HOB
INVERTER
DC / AC
POWER BUS DC - 12 V
