Step Thirty Two: Install the Remote Switch Box to the switch plate on the motor
using (4) 1/4”*3/4” hex bolts and (4) 1/4”*OD19*2t flat washers.
Step Thirty Three: Take the paddle and paddle branch and assemble together
using (4) 1/4”*5/8” hex bolts, (8) 1/4”*OD13*1t flat washers and (4) 1/4” hex nuts.
Step Thirty Four: Assemble the two paddle and paddle branch assemblies to the
rotation shaft using (4) 1/4”*5/8” hex bolts, (8) 1/4”*OD13*1t flat washers and (4)
1/4” hex nuts.
