Operator's Manual – Slam'N'Jam
©
LAI GAMES
SLAM N‟ JAM ASSEMBLY Quick Guide
Do‟s and Don‟ts for Assembling Slam„N‟Jam
Do read the Slam„N‟Jam assembly manual as it will help you in the
correct step by step order of assembly
Do take note of what size bolts are used where when assembling
Slam„N‟Jam
Do make sure that all cables are free to move and not pinched or
jammed under the playfield or other parts when assembling
Slam„N‟Jam.
Do make sure that all earth point cables are connected when
assembling both the Front Frames and Front Playfield Speaker Pods
on Slam„N‟Jam.
Don‟t forget to remove the Slam„NJam keys from inside the game
cabinet before bolting the front playfield in place.
Don‟t forget after assembling Slam„N‟Jam to check and tighten all the
bolts.
Don‟t forget to check the voltage setting of Slam„NJam is set to the
mains voltage for your country before applying power.
TIPS for Assembling Slam„N‟Jam
We recommend using two people when assembling Slam„N‟Jam. While one
person is able to do most of the assembly, using two people will be much easier. A
stepladder will also be very handy during assembly.
We Recommend that assembling Slam„N‟Jam is best done on a level and even
surface. Adjust the rubber feet on the frames to align them for easier assembly.
We recommend when assembling Slam„N‟Jam not tightening all the bolts until all
major parts are fitted. This will allow the easy alignment of holes as the frame is
not held rigid.
.
* NOTE! *
Slam„N‟Jam uses metric size Nuts & Bolts throughout its construction
To help in ease of moving Slam„N‟Jam the machine can be split into two
separate halves. Remove the eight Bolts holding the Front and Rear Frame
Halves together and unplug the main backboard and lighting cables at the
connectors near the Ball Gate. The Ball Gate stays fixed to the front half of
the machine.
