Lailey abd Coates LC-07 - Technical Specification

Installation Manual 2013 Riv 2 6
Indoor unit LC-07 LC-10 LC-12 LC-15
Dimensions indoor unit
Height mm 549 549 609 609
Width mm 450 450 450 450
Depth mm 262 262 262 262
Weight
Gross Kg 35 36 39 40
Net Kg 30 31 34 35
Sound pressure level dBA 26 27 28 29
Water flow temperature Heating max ⁰C 55 55 55 55
Minimum water flow L / min 12 18 24 30
Pump heat at min flow ⁰C 55 55 55 55
Electrical Heaters
Power Supply W 220-240v
Capacity kW 3 kW 3 kw 4 kW 4 kW
*TaDB/WB7⁰C/6⁰CLWC35⁰C ∆T5⁰C as per EN 14511
Technical Specification
Outdoor Unit LC-07 LC-10 LC-12 LC-15
Power supply 220-240v 50 Hz
Nominal capacity * Heating kW 6.93 9.68 12.67 15
Nominal input * Heating kW 1.43 2.05 2.73 3.33
COP*7⁰C(A7/W35) Heating kW 4.84 4.73 4.64 4.5
Outdoor temperature range
Min ⁰C -15 -15 -15 -15
Max ⁰C 35 35 35 35
Refrigerant pipe diameter Diameter ins
½ - ⁄ ⁄ - ⁄ ¾ - ⁄ ¾ - ⁄
Refrigerant Type
R 410 a
R 410 a
R 410 a
R 410 a
Compressor Rotary DC compressor
Fan Speed Variable
Heater mats fitted Yes Yes Yes Yes
Sound pressure level Heating dBA 48 50 51 52
Maximum pipe run (indoor to outdoor unit) Maximum m 15 20 20 25
Piping connections (flow and return)  ⁄ " (female)
Dimensions outdoor unit
Height mm 892 892 1250 1250
Width mm 963 963 963 963
Depth mm 342 342 343 343
Weight
Gross Kg 105 108 118 120
Net Kg 89 92 101 103
