CHECKING NOMINAL HEAT CAPACITY
SAGB.... - SAGV.... - ARGS....
- Chamber Burner
Check the depth of the screw “A” in
accordance with table 5
of the “Tecnical gas
data” booklet,
using a gauge.
Check that the burner fan speed, corresponds
to the data given in table 5 of the “Technical
gas data” booklet.
To enter the management screen of the burner to
check:
With the appliance live and display off, press
button 1, the display 2 shows [USb], turn knob 3
until [rEL] is displayed, press the knob to confirm
the selection
Turn knob 3 to set the password for parameter
modification and confirm by pressing knob 3.
13 • OPERATING AT THE RATED HEAT OUTPUT
1
2
3
5
4
A
3
