Display
3.83-inch (diagonal) white monochrome OLED
320x132-pixel resolution at 16-bit grayscale
Chip
Intel® Altera® Cyclone® FPGA
Clock
CCHD-957 FEMTO Clock Ultra-Low Phase Noise Oscillator
Digital Inputs
1 x USB
1 x Optical
1 x Coaxial
1 x I
2
S
Analog Outputs
1 x XLR, maximum at 4.15Vrms, approx. 1200
Ω
1 x RCA, maximum at 2.07Vrms, approx. 600
Ω
Supported Formats
(Input dependent)
USB - PCM: 44.1kHz - 768kHz | DSD: DSD64 - DSD256
Optical - PCM: 44.1kHz - 192kHz | DSD: Not Supported
Coaxial - PCM: 44.1kHz - 192kHz | DSD: Not Supported
I2S - PCM: 44.1kHz - 768kHz | DSD: DSD64 - DSD256
Frequency
Response
20Hz – 20kHz, within ± 0.25 dB
3
THD+N
0.0035%
3
Crosstalk
Better than 110 dB, 20Hz – 20kHz
3
Signal to Noise
Ratio (SNR)
Better than 123dB, A-Wt.
3
Dynamic Range
Better than 110dB, A-Wt.
3
3.83”
