LAMAR LS 70 - Page 5

Item # Part Number Description
1 13065 Base Frame
2 24110 Leg Extension Arm
3 24116 Foot Plate (Base)
4 24122 Vertical Upright
5 24111 Upper Pulley Housing
6 24112 Lat Bar Holder
7 24117 Folding Foot Plate
8 24119 Range of Motion Assembly
9 24120 Press Arm Assembly
10 13062 Seat Adjustment Post
11 24114 Roller Pad Pivot
12 27051 Free Motion Assy
13 27052 Swivel Pulley Housing
14 20008 Floating Pulley (Single)
15 27027 Lat Bar
16 27020 Curl / Pull Bar
17 24108 Base Assembly
18 05104 Roller Bar
19 26003 Guide Rod
20 27053 Pulley Caps
21 24123 Side Brace
22 13064 Back Pad Mounting Plate
23 24107 Mounting Bracket (Floating Pulley Assembly)
24 07017 Shroud (Weight Plate / Guide Rod)
25 07018 Shroud (Weight Plate / Guide Rod)
26 25003 Selector / Top Plate Assembly
27 01199 Pivot Shaft 25 x 229L
28 01223 (Large) Hinge Pin 9.5 x 240L
29 01198 Threaded Shaft 25 x 76L
30 01097 Bushing Sleeve 19 x 13.1 x 89L
31 01201 Cable Mounting Barrel 25.4 x 60L
32 01203 Carriage Bolts 1/2"-13UNC x 2.75" Length
33 01150 Button Head Allen Screw 1/2'-13UNC x 6.25" Length
34 01153
Button Head Allen Screw 1/2'-13UNC x 6.00" Length
35 01067 Button Head Allen Screw 1/2'-13UNC x 5.00" Length
36 01189 Button Head Allen Screw 1/2'-13UNC x 4.75" Length
37 01205 Button Head Allen Screw 3/8"-16UNC x 5.25" Length
38 01206 Button Head Allen Screw 3/8"-16UNC x 4.75" Length
LS 70 GYM
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
2
2
2
2
1
4
1
1
1
1
1
1
1
1
2
1
1
2
1
16
5
Quantity
PAGE 4
