Remove the lid
Unscrew the 6 screws and remove the plastic cover.
Unscrew the 3 screws and remove the aluminium cover.
Unscrew the 2 screws and remove the motor module.
Turn upside-down the motor module.
Fuse = F5A
Connect the wires, see the tables and the drawing.
Re- insert the motor module and screw the 2 screws.
Re- insert the aluminium coverage and screw the 3 screws.
Re- insert the plastic cover and screw the 6 screws.
