CHANNEL 12: FADE SPEED
This channel allows the users to force a fade time (from 0s to 0,5s) to the speed of the r,g,b,a,dimmer channels.
This function is very helpful for use the flash button of many consolle.
DMX value function
0 NO FADE
From 1 to 255 Fade from 0s to 0,5s
CHANNEL 13: FREQUENCY (ONLY FOR PROFESSIONAL USE)
This channel allows to change led control frequency from 244Hz to 1KHz, necessary for STUDIOS, THEATRES and for
CAMERA RECORDING.
DMX value function
0 FREQUENCY of 244Hz
From 1 to 254 Proportional frequency increase
255 FREQUENCY of 1000Hz
CHANNEL 14: FREQUENCY fine (ONLY FOR PROFESSIONAL USE)
Fine FREQUENCY regulation (16bit)
DMX value function
From 0 to 255 16bit FREQUENCY regulation
Spare parts
When ordering spare parts remember to mention the model, the serial number and year of production of the projector.
Call your area dealer or feel free to contact the manufacturer for any additional assistance. See spare parts list below.
LED036 1 Narrow 35mm lens 12°
LED037 1 Medium 35mm lens 30°
LED038 1 Wide 35mm lens 45°
SCH99/034 1 Power PCB
SCH99/036 1 CPU PCB
SCH99/038 1 Display PCB
SCH99/049 1 Interface keyboard
CAV99/044 0.6meter cable with Neutrik NC3 X-HD IP65 XLR 3pin female connector (IN)
CAV99/045 0.6meter cable with Neutrik NC3 X-HD IP65 XLR 3pin male connector (OUT)
CAV99/037 Polyurethane flexible signal cable for out-door. One pair plus shield, 120 Ohm.
CON99/011 Neutrik NC3 X-HD IP65 XLR 3pin male connector
CON99/012 Neutrik NC3 X-HD IP65 XLR 3pin female connector
CAV99/032 1meter neoprene cable with male connector (IN) IP65 Weiland RST20i3
CAV99/042 1meter neoprene cable with female connector (OUT) IP65 Weiland RST20i3
CAV99/031 Female connector (IN) IP65 Weiland RST20i3 for power supply
CAV99/041 Male connector (OUT) IP65 Weiland RST20i3 for power supply
CAV99/033 End cap for unused IP65 male connector
CAV99/034 End cap for unused IP65 female connector
The improper use of this projector, cancel the guarantee and our responsibility. All the information have been written and driven with
extreme care; however, we do not engage us any responsibility for contingent errors or omissions. We reserve the right to modify and/ or
improve our product as we retain necessary, without subsequent warning or notice. It is forbidden any complete or partial reproduction of
this handbook, if not expressly authorized.
