BEFORE CONNECTING AND USING THE PROJECTOR, IT IS IMPORTANT TO READ CAREFULLY ALL THE
INSTRUCTIONS IN THIS MANUAL.
QUALIFIED PERSONNEL ONLY, IN COMPLIANCE WITH ALL THE SECURITY LAWS, CAN DO THE
INSTALLATION, THE MAINTENANCE AND THE UTILISATION OF THIS PROJECTOR.
BEFORE CONNECTING THE PROJECTOR, MAKE SURE THAT THE FREQUENCY AND THE VOLTAGE
VALUES ARE SUITABLE AS SPECIFIED ON THE PROJECTOR.
FOR ANY DOUBT, CONTACT YOUR SUPPLIER OR SEND AN E-MAIL TO:
tech@lamposrl.it
LED RADIATION, DO NOT STARE INTO BEAM, CLASS 2 LED PER IEC 60825-1.
For additional information on these led devices with regard to the IEC 60825-1 standard, contact SEOUL Semiconductors.
SOLID: Dust-tight
WATER: Protected against heavy seas
Suitable for direct mounting on normally flammable surfaces
Minimum distance from lighted objects (0.3 meters)
Rated maximum ambient temperature (indoor without high-temperature control)
Connection must be made to a power supply system fitted with efficient
earthing (EN60598-1 – Class I fixture)
Replace any cracked protective shield, dichroic filter or lens
Index
Dimensions and weight -------------------------------------------------------------------------------- page 2
Technical data ------------------------------------------------------------------------------------------- page 2
Storage ---------------------------------------------------------------------------------------------------- page 2
Admissible environmental conditions --------------------------------------------------------------- page 2
Installation ----------------------------------------------------------------------------------------------- page 3
Example of installation --------------------------------------------------------------------------------- page 3
Signal cable selection ----------------------------------------------------------------------------------- page 4
EIA485 specifications ----------------------------------------------------------------------------------- page 4
Power supply connection ------------------------------------------------------------------------------ page 5
DMX signal connection -------------------------------------------------------------------------------- page 5
Schematic menu ----------------------------------------------------------------------------------------- page 6
User’s interface ------------------------------------------------------------------------------------------ page 7
Functions menu ------------------------------------------------------------------------------------------ page 7
DMX control mode -------------------------------------------------------------------------------------- page 9
Spare parts ------------------------------------------------------------------------------------------------ page 16
