Lampo IP66 LED - Technical Data; Admissible Environmental Conditions

2
Dimensions & weight
Weight: 5,2 Kg
Technical data
- Aluminium body with cooling fins
- IP66 protection rate
- Thermal-shock resistant glass, IK08
- The projector can be installed in any position
- Input voltage range: from 85 to 265 Vac
- Frequency: 50-60 Hz
- 0,95 PFC electronically controlled
- Current controlled led
- Max power consumption: 44W (When all led are on at max power)
- 12 LEDs full colour 3.6W P5 by SEOUL Semiconductors (each LED’s case contain 77Lumen of RGB dices)
- High quality 35mm PMMA lenses by FRAEN
- Works via signal DMX
- Works in stand alone mode (Master/Slave)
- Can works in stand alone mode via infra-red remote control
- LED remote control code AS148
Storage
The projector, in its original packing, must be kept in covered, dry areas with a temperature between –10°C and +50°C.
Attention, the projector will be damaged during the unpacking.
Admissible environmental conditions
The projector was engineered and produced to function in outdoor areas with an air temperature ranging between -20°C and
+50°C (thanks to inside high-temperature control) and with a humidity level between 30 and 90%.
When choosing the installation, please make sure that the device is not exposed to extreme heat or in small area.
