8
Go to this submenu pushing Mode , choose DM.ST with + and - and push Enter . Use + and - to select the desiderate
value and push Enter to confirm
Admissible mode:
15.ON, (15% ON) r,g,b,a channels ON at 15%
A.ON, (ALL ON) r,g,b,a channels ON at 100%
A.OFF, (ALL OFF) r,g,b,a channels OFF
- MA.IR: (master infrared) Whit I.R. sensor cabled, the board can run one of the stored Chase or do a fixed colour, that can
be controlled by the LED REMOTE.
LED REMOTE has 10m (free air) capacity.
Default value ON
Go to this submenu pushing Mode , choose MA.IR with + and - and push Enter . Use + and - to select the ON or OFF
and push Enter to confirm.
With red button of the LED REMOTE, you can switch ON or OFF the leds (ATTENTION: when you switched OFF the led,
the board is still running!!! ), with P+ e P- you can choose the program or change the colour. This function allows to use the
MASTER/SLAVE function.
ATTENTION: Disable MA.IR function on Slave boards. Two boards in Master mode can do several errors on DMX
transmission.
- ST.AL: (stand alone) The board can run in StandAlone mode with Master/Slave function.
Default value MS00
Go to this submenu pushing Mode , choose ST.AL with + and - and push Enter . Use + and - to select the macro
needed and push Enter to run it.
The board run in loop mode the Macro selected from M01 to M26 and output the DMX signal (master mode) for the other
board (slave).
To use Master/Slave function, all the boards need to be patched with the dmx patch 7C d !
StandAlone mode remains also if power supply is interrupted.
Macro Mode
Colour changing
time (seconds)
Colour holding
time (seconds)
MA01
SLOW rainbow without amber 20 5
MA02
MEDIUM rainbow without amber 10
5
MA03
FAST rainbow without amber 5
5
MA04
SLOW rainbow without amber 20
2
MA05
MEDIUM rainbow without amber 10
2
MA06
FAST rainbow without amber 5
2
MA07
Very SLOW rainbow without amber 40
NO
MA08
SLOW rainbow without amber 20
NO
MA09
MEDIUM rainbow without amber 10
NO
MA10
FAST rainbow without amber
5 NO
MA11
SLOW Random colours without amber 10 NO
MA12
MEDIUM Random colours without amber 5 NO
MA13
FAST Random colours without amber 2 NO
MA14
SLOW rainbow + amber 20
5
MA15
MEDIUM rainbow + amber 10
5
MA16
FAST rainbow + amber 5
5
MA17
SLOW rainbow + amber 20
2
MA18
MEDIUM rainbow + amber 10
2
MA19
FAST rainbow + amber 5
2
MA20
Very SLOW rainbow + amber 40
NO
MA21
SLOW rainbow + amber 20
NO
MA22
MEDIUM rainbow + amber 10
NO
MA23
FAST rainbow + amber 5
NO
MA24
SLOW Random colours + amber 10 NO
MA25
MEDIUM Random colours + amber 5 NO
MA26
FAST Random colours + amber
2
NO
