Correcting Faults
6.1.3
Call of the Fault History
In the MAIN MENU, select
for informa-
tion.
In INFORMA
TION, select
for the fault
history
.
Fault history
01
Number of the entry
001
Fault number of the main pr
ocessor
If
the
fault
number
is
displayed
as
"101"
(+100),
there is
a
fault
in
the
monitoring
processor
.
1
T
rigger 1
0h
O
ccurs in case of ... Operating hours
For fault numbers, see Chapter
6.1.1 Faul
ts
.
41
43
