O P E R A T I O N PAGE 10
Last printed 1/31/2012 4:04:00 PM
Version Rev. 2003D-0
Setting the Control Timer
Direct Start Continuous Tumbling
1. Press (RST/ENT) button on the tumbler timer.
2. Set the set-point on the tumbler timer for total tumbling time (time required for the
drum to rotate).
3. To set the time on the tumbler timer press the (PR) button.
4. Notice the number that is flashing. Press the button with the arrow pointing to right
to the desired position you want to change (the timer is set for hour-minute).
5. Press the button with the arrow pointing up to set the desired time (each position
must be done separately).
6. After the time is set, press the (RST/ENT) button to enter the time.
7. Press the (RST/ENT) again to change the current time on the timer.
8. The tumbler timer is ready to run.
9. Press the tumbler start button to begin the cycle.
Stopping the tumbler with the tumbler STOP button or photo-eye will stop the tumbler
timer and maintain its time.
Pressing the tumbler START button will restart the tumbler timer from where it left off.
Pressing the reset button on the tumbler timer in the middle of a tumbling cycle will
reset the timer to the preset time setting.
