lancer 1500 - Wiring Diagrams

15
Wiring Diagrams
Model 2500
GREEN
BLACK
WHITE
021 CA
JCT.
AGITATOR
MOTOR
LANCER
ICE
BANK
CONTROL
PROBE
RELAY
FAN
MOTOR
COMPRESSOR
OVERLOAD
C
M
S
L
M
S
WHEN STARTING UNIT OR IF CURRENT IS INTERRUPTED, THERE IS
A FIVE (5) MINUTE DELAY BEFORE THE COMPRESSOR/FAN STARTS.
IMPORTANT
Model 1500
AC POWER IN
AGITATOR
MOTOR
WHITE
BLACK
GREEN
KILL
SWITCH
JCT
COMPRESSOR
LANCER
ICE
BANK
CONTROL
PROBE
L
RELAY
S
M
M
S
FAN
MOTOR
C
OVERLOAD
