BEFORE GETTING STARTED
Each unit is tested under operating conditions and is thoroughly
inspected before shipment. At the time of shipment, the carrier
accepts responsibility for the unit. Upon receiving the unit, care-
fully inspect the carton for visible damage. If damage exists, have
the carrier note the damage on the freight bill and le a claim
with carrier. Responsibility for damage to the chiller lies with the
carrier.
The installation or relocation of this product must be carried out by qualied personnel with
up-to-date safety and hygiene knowledge and practical experience, in accordance with current regulations.
IMPORTANT SAFETY INSTRUCTIONS...................................2-3
Intended Use..........................................................................3
Electrical Warning..................................................................3
CO
2
Warning..........................................................................3
Water Notice...........................................................................3
PRE-INSTALLATION.................................................................4-6
Specication & Features......................................................4-5
General System Overview......................................................6
Pre-Installation Checklist........................................................6
INSTALLATION.......................................................................7-8
Unpacking the Chiller............................................................7
Selecting/Preparing a Counter Location................................7
Chiller Installation..................................................................8
CLEANING AND SANITIZING......................................................9
General Information...............................................................9
Cleaning and Sanitizing Solutions..........................................9
Cleaning and Sanitizing Syrup Lines .....................................9
MAINTENANCE..........................................................................10
TROUBLESHOOTING...........................................................10-14
ILLUSTRATIONS AND PART LISTINGS..............................13-17
Cabinet Assembly...........................................................13-14
Wiring Diagrams...................................................................15
Plumbing Diagrams.........................................................16-17
READ ALL SAFETY INSTRUCTIONS BEFORE USING THIS UNIT.
This manual contains important safety information and all applicable safety precautions must be observed. To reduce the
risk of re, electric shock, damage to the equipment or personal injury when using this unit all instructions/warnings on
the product being used must be followed. Be sure to read all Warning, Caution, Attention, and Note statements before
proceeding with the installation.
Text following the Warning signal indicates a
hazardous situation, which if not avoided, will result in
death or serious injury.
! WARNING
Text following the Caution signal indicates a
hazardous situation, which if not avoided, could result
in death or serious injury.
! CAUTION
Text following the Attention signal addresses a
situation that if not followed could potentially damage
the equipment.
! ATTENTION
Text following the Note signal provides you with
 informationthatmayhelpyoumoree󰀨ectivelyperform
the installation procedures within this manual.
Disregarding information will not cause damage or
injury, however it may limit the performance of the
chiller.
NOTE
ABOUT THIS MANUAL
This booklet is an integral and essential part of the product and
should be handed over to the operator after the installation for fu-
ture reference. Please read carefully the guidelines and warnings
contained herein as they are intended to provide the user with
essential information for the continued safe use and maintenance
of the product. In addition, it provides GUIDANCE ONLY to the
user on the correct services and site location of the unit.
