4
19 in
477 mm
19 in
486 mm
26 in
650 mm
DIMENSIONS
Width: 19 inches (486 mm)
Depth: 19 inches (477 mm)
Height: 26 inches (650 mm)
WEIGHT
Shipping: 150 lbs (68 kg)
Operating: 261 lbs (118 kg)
ELECTRICAL
115 VAC, 60 Hz, 7.8 Amps
230 VAC, 50 Hz, 4.5 Amps
WATER SUPPLY
Min Inlet Pressure: 25 psi (0.172 MPa)
Max Static Pressure: 70 psi (0.483 MPA)
FITTINGS AT UNIT
Inlets : 3/8 inch barb
Outlets: 3/8 inch barb
A
B
C
A. Bonnet
B. Water and Syrup
Inlets & Outlets
C. Front Plate
This unit emits a sound pressure level below 70 dB.
Max Altitude: 16,400 ft (5,000 m)
SPECIFICATIONS AND FEATURES
1500 Specifications
