5
31 in
777 mm
26 in
659 mm
22 in
553 mm
DIMENSIONS
Width: 26 inches (659 mm)
Depth: 22 inches (553 mm)
Height: 31 inches (777 mm)
WEIGHT
Shipping: 300 lbs (136 kg)
Operating: 479 lbs (217 kg)
ELECTRICAL
115 VAC, 60 Hz, 16 Amps
230 VAC, 50 Hz, 7.5 Amps
WATER SUPPLY
Min Inlet Pressure: 25 psi (0.172 MPa)
Max Static Pressure: 70 psi (0.483 MPA)
FITTINGS AT UNIT
Inlets : 3/8 inch barb
Outlets: 3/8 inch barb
A. Bonnet
B. Water and Syrup
Inlets & Outlets
C. Front Plate
This unit emits a sound pressure level below 70 dB.
Max Altitude: 16,400 ft (5,000 m)
A
B
C
2500 Specifications
