User Guide User Guide
Page 14 PP307 Page 14 PP307
• Mouse-over ‘Parameters’ to reveal the ‘Off-line Commissioning
(Restricted)’ option. This screen allows restricted access, via a further
password screen, to commissioning options. During access to this
screen, thermometer setup is carried out off-line.
• Click to reveal the ‘Sign In’ screen (see Fig. 11).
• Enter Land in the ‘User Name’ box.
• Enter offline in the ‘Password’ box.
• Press ‘Continue’.
• The ‘Off-line Commissioning (Restricted)’ screen appears (see Fig. 12).
2
1
3
4.1.3 ‘Off-line Commissioning (Restricted)’ Page Access
Item Description User Settable Function
Contact Mode: ‘NC’ (Normally Closed), ‘NO’
(Normally Open)
NOTE: For ‘failsafe’ operation use the ‘NC’ option
AL2 Level (°) - Set alarm 2 temperature level
Mode - Low Alarm: indicates when the process
temperature falls below the set specified limit
High Alarm: alarm level set to high range value
Ambient Alarm: alarms when the internal
thermometer temperature exceeds the safe internal
ambient limit
E/NG Lost Alarm: alarm set to indicate loss of
emissivity/non-greyness signal
Obscuration Alarm: alarm level set to indicate
excessive obscuration (Ratio thermometers only)
Contact Mode: ‘NC’ (Normally Closed), ‘NO’
(Normally Open)
NOTE: For ‘failsafe’ operation use the ‘NC’ option
10 Serial Number No Displayed as read from instrument
11 RS485 Address Yes User setable RS485 address (1-254)
12 Configuration Yes Read - Refreshes the values displayed
Apply - Transfers the set values to the
thermometer and saves the set values to non-
volatile memory of the thermometer (greyed-out if
no changes have been made)
• Mouse-over ‘Parameters’ to reveal the ‘Off-line Commissioning
(Restricted)’ option. This screen allows restricted access, via a further
password screen, to commissioning options. During access to this
screen, thermometer setup is carried out off-line.
• Click to reveal the ‘Sign In’ screen (see Fig. 11).
• Enter Land in the ‘User Name’ box.
• Enter offline in the ‘Password’ box.
• Press ‘Continue’.
• The ‘Off-line Commissioning (Restricted)’ screen appears (see Fig. 12).
2
1
3
4.1.3 ‘Off-line Commissioning (Restricted)’ Page Access
Item Description User Settable Function
Contact Mode: ‘NC’ (Normally Closed), ‘NO’
(Normally Open)
NOTE: For ‘failsafe’ operation use the ‘NC’ option
AL2 Level (°) - Set alarm 2 temperature level
Mode - Low Alarm: indicates when the process
temperature falls below the set specified limit
High Alarm: alarm level set to high range value
Ambient Alarm: alarms when the internal
thermometer temperature exceeds the safe internal
ambient limit
E/NG Lost Alarm: alarm set to indicate loss of
emissivity/non-greyness signal
Obscuration Alarm: alarm level set to indicate
excessive obscuration (Ratio thermometers only)
Contact Mode: ‘NC’ (Normally Closed), ‘NO’
(Normally Open)
NOTE: For ‘failsafe’ operation use the ‘NC’ option
10 Serial Number No Displayed as read from instrument
11 RS485 Address Yes User setable RS485 address (1-254)
12 Configuration Yes Read - Refreshes the values displayed
Apply - Transfers the set values to the
thermometer and saves the set values to non-
volatile memory of the thermometer (greyed-out if
no changes have been made)
