8.913-910.0 • LANDA PG • Rev. 11/11B
OPERATOR’S MANUAL
PRESSURE WASHER
18
EXPLODED VIEW - 4-2000, 4-3500 PARTS LIST
ITEM PART NO. DESCRIPTION QTY
2 8.718-980.0 Washer, 5/16" Flat, SAE 6
3 8.900-818.0 Label, Operating Inst/Warn 1
4 8.706-655.0 Guard, Belt, PG Small, Plastic 1
(4-2000)
8.706-656.0 Guard, Belt, PG Large, Plastic 1
(4-3500)
5 9.802-066.0 Pad, Soft Rubber 2
6 9.802-819.0 Washer, 7/16" x 2-1/2", Zinc 2
7 8.718-674.0 Bolt, 3/8-16 X 2-1/4",GR8.2
Whiz Loc 8
8 9.802-811.0 Washer, 3/8" x 1-1/2", Fender 1
9 Engine Bushing, See Specifi cations Pages
10 Pump Bushing, See Specifi cations Pages
11 Engine Pulley, See Specifi cations Pages
12 Pump Pulley, See Specifi cations Pages
13 Belt, See Specifi cations Pages
14 8.911-286.0 Back Plate, Belt Guard, 1
PG Small (Landa Pump)
8.933-026.0 Back Plate, Belt Guard, Large 1
(PG4-3500)
15 8.900-412.0 Label, 4-3500 Lexan 1
8.900-409.0 Label, 4-2000 Lexan 1
16 Engine, See Specifi cations Pages
17 8.932-993.0 Cushion, Pump, Thin 1
18 9.802-125.0 Plug, 1/4" JIC 1
19 9.802-153.0 Swivel, 1/4" JIC Fem, Push-on 1
20 9.803-098.0 Hanger, Hose & Wand 1
21 9.802-154.0 Plug, Push-on, Oil Drain 1
22 9.197-003.0 Nut, 3/8" ESNA, NC 12
23 9.198-004.0 Washer, 3/8" Uss F/w Zinc 18
24 9.802-810.0 Washer, 5/8" Flat, SAE 4
25 8.718-835.0 Nut, 5/8" Jam, ESNA, NC 2
26 8.718-684.0 Bolt, 3/8" x 5" NC 2
27 8.911-289.0 Frame, PG/PE Small (4-2000) 1
8.920-223.0 Frame, Large Belt Drive 1
(4-3500)
28 8.920-250.0 Bumper, 1-1/4" Chrome Grab 1
29 9.802-733.0 Bolt, 3/8" x 3-1/2", Tap 2
30 9.802-728.0 Bolt, 3/8" x 2" 2
31 8.900-247.0 Label, PG (Lexan) 1
32 9.802-270.0 Wheel & Tire Assy, 4" Tube 2
(4-2000)
9.802-271.0 Wheel & Tire, 6" Steel Rim 2
(4-3500)
33 8.719-905.0 Bracket, Belt Tension 1
34 9.800-034.0 Label, Clear Lexan 1
ITEM PART NO. DESCRIPTION QTY
35 9.802-789.0 Nut, 3/8", Hex, NC 3
36 8.933-025.0 Handle, 1-1/4" Chrome Plated 1
37 9.802-064.0 Grommet, Rubber (4-3500) 4
(4-2000) 5
38 8.712-345.0 Nozzle, SAQCMEG 0004, 1
Red (4-3500)
8.712-346.0 Nozzle, SAQCMEG 1504, 1
Yellow (4-3500)
8.712-347.0 Nozzle, SAQCMEG 2504, 1
Green (4-3500)
8.712-348.0 Nozzle, SAQCMEG 4004, 1
White (4-3500)
8.712-361.0 Nozzle, SAQC Meg 0006, 1
Red (4-2000)
8.712-362.0 Nozzle, SAQC Meg 1506, 1
Yellow (4-2000)
8.712-363.0 Nozzle, SAQC Meg 2506, 1
Green (4-2000)
8.712-364.0 Nozzle, SAQC Meg 4006, 1
White (4-2000)
39 Pump, See Specifi cations Pages
40 9.802-811.0 Washer, 3/8" x 1-1/2" Fender 6
41 9.802-870.0 Block, Unloader, 3/8" x 3/8", 1
1.25, Steel
42 9.802-728.0 Bolt, 3/8" x 2", NC HH 2
43 8.705-974.0 Nipple, 3/8" Hex Steel 1
44 9.802-129.0 Elbow, 1/2" JIC x 3/8", 90° 1
45 9.802-720.0 Bolt, 3/8" x 1" NC 2
46 9.802-036.0 Nipple, 1/2" JIC, 3/8" Pipe 1
47 9.197-003.0 Nut, 3/8" ESNA, NC 2
48 9.802-807.0 Washer, 3/8" SAE, Flat 2
49 9.802-039.0 Elbow, 1/2" JIC, 3/8", 90° 1
50 8.918-424.0 Hose, 3/8" x 25", 2 Wire 1
Pressure Loop
51 Unloader, See Specifi cations Pages
52 9.802-128.0 Nipple, 1/2" JIC x 1/2" 1
MPT Pipe
53 8.706-860.0 Tee, 1/2", Street 1
54 9.802-151.0 Swivel, 1/2" JIC Fem, Push-On 2
56 9.800-006.0 Label, Hot/Caliente 1
57 9.800-008.0 Label, Danger Cool Engine 1
58 9.802-259.0 Hose, 1/2", Push-On 15”
59 9.802-720.0 Bolt, 3/8" x 1" NC, HH 1
60 9.802-067.0 Bumper Pad, Engine 1
61 9.802-807.0 Washer, 3/8" SAE, Flat 4
62 9.197-003.0 Nut, 3/8" ESNA, NC 4
63 9.802-776.0 Nut, 5/16" ESNA 3
64 8.707-254.0 Pump Protector, 3/8" PTP 1
65 8.911-293.0 Bracket, Wide Foot 1
To Next Page
