PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW - 4-4000, 5-3500 PARTS LIST
ITEM PART NO. DESCRIPTION QTY
52 8.719-902.0 Handle, Bumper 1-1/4" 1
Chrome Grab
53 9.802-789.0 Nut, 3/8" Hex, NC 2
54 8.906-774.0 Foot Assy, PG 2
55 8.706-557.0 Bellow, Leg (Boot) 2
56 8.718-684.0 Bolt, 3/8" x 5" NC, HH, Tap 2
57 9.802-817.0 Washer, 3/8" x 1" 2
58 9.802-819.0 Washer, 7/16" x 2-1/2" Zinc 2
59 8.719-091.0 Spring, Foot, Compression 2
60 8.719-954.0 Tube, Foot Bolt, PC 2
61 9.802-066.0 Pad, Soft Rubber 2
62 8.911-258.0 Holder, Battery, PG 1
63 8.719-901.0 Clamp, Battery, PG 1
64 8.719-905.0 Back Plate, Belt Guard, PG, Lg. 1
65 9.198-014.0 Washer, 5/16" x 1-1/4", Fender, 6
SAE (Vanguard)
9.802-811.0 Washer, 3/8" x 1-1/2" Fender 6
(Honda)
66 Engine Bushing, See Specifi cations Pages
67 Engine Pulley, See Specifi cations Pages
68 Pump Pulley, See Specifi cations Pages
69 Belt, See Specifi cations Pages
70 Pump Bushing, See Specifi cations Pages
71 8.705-974.0 Nipple, 3/8" Hex 1
72 9.802-129.0 Elbow, 1/2" JIC x 3/8" 1
73 9.802-720.0 Bolt, 3/8" x 1" NC, HH 4
74 9.800-008.0 Label, Danger Cool Engine 1
75 8.706-940.0 Hose Barb, 1/4" Barb x 1/8" ML 2
(Fuel Tank Assy 4-40324E)
76 9.802-730.0 Bolt, 3/8" x 2-1/2" GR 5 ZN 2
77 8.707-178.0 Coupler, Fuel Line, Quick 1
(4-40324E)
78 8.706-941.0 Hose Barb, 1/4" Barb x 1/4", 1
ML Pipe
79 8.751-294.0 Fuel Tank, 6 Gal (4-40324E) 1
80 9.800-006.0 Label, Hot 1
81 9.802-776.0 Nut, 5/16" ESNA (Vanguard) 4
9.197-003.0 Nut, 3/8" ESNA, (Honda) 4
82 8.718-980.0 Washer, 5/16" Flat 4
(Vanguard)
9.802-807.0 Washer, 3/8" Flat 4
( Honda)
83 8.750-737.0 Adapter, 3/8" x 1/4" 1
( Honda)
84 9.800-049.0 Label, Manufacturer’s Cleaning 1
Solution
ITEM PART NO. DESCRIPTION QTY
85 9.802-259.0 Hose, 1/2” Push-On 4”
86 9.802-710.0 Bolt, 5/16” x 1” NC, HH 2
87 8.932-968.0 Label, Intended For Outdoor 1
88 9.800-034.0 Label, Clear Lexan 1
89 9.802-727.0 Bolt, 3/8" x 1-3/4" Tap 2
90 8.751-101.0 Terminal, Ring Tongue, S6-38R 4
91 9.803-836.0 Wire, THWN 6 GA Red 17"
92 9.803-837.0 Wire, THNN, 6 GA Black 17"
93 9.802-744.0 Bolt 10mm x 20mm HH 4
94 9.802-816.0 Washer 7/16 Lock Split 4
95 8.917.015.0 Label, Regulation 4442.6 1
▲ Not Shown
To Next Page
