Landa PG4-2000 - Downstream Injector Assembly; Assembly Diagram and Parts List

8.913-910.0 • LANDA PG • Rev. 11/11B
25
PRESSURE WASHER
OPERATOR’S MANUAL
DOWNSTREAM INJECTOR ASSEMBLY
ITEM PART NO. DESCRIPTION QTY
1 9.802-216.0 Detergent Injector Non Adjust, #3 1
2 9.802-210.0 Clamp, Hose, UNI .46 - .54 2
3 9.802-251.0 Tube, 1/4" x 1/2", Clear Vinyl 6 ft.
4 8.707-057.0 Strainer, 1/4" Hose Barb 1
1
2
3
4
2
DOWNSTREAM INJECTOR ASSEMBLY
