LANDA PG 8.913-910.0
OPERATOR’S MANUAL
PRESSURE WASHER
28
LT PUMP EXPLODED VIEW PARTS LIST (CONT)
REPAIR KIT NUMBER
8.753-821.0 8.753-822.0 8.753-823.0 8.753-824.0 8.752-835.0
KIT DESCRIPTION
Plunger Seal
18mm
Seal Packing
18mm Plunger 18mm Complete Valve Plunger Oil Seals
ITEM NUMBERS
INCLUDED
3,5,7 3,4,5,6,7 34,35,36,37 11,12,13 2
NUMBER OF CYLIN-
DERS KIT WILL SERVICE
3 1 1 6 3
ITEM PART NO. DESCRIPTION QTY
35* 8.752-820.0 Bonded Seal 3
36* 8.753-819.0 Plunger 18mm 3
37* 8.752-823.0 Copper Spacer 3
38 See Kit Below Plunger Rod 3
39 8.752-822.0 Connecting Rod Pin 3
40 8.752-821.0 Connecting Rod 3
41 9.802-889.0 Spring Washer 6
42 9.802-937.0 Connecting Rod Screw 6
43 9.803-194.0 O-Ring Ø2.62 x 152.07 1
44 8.752-826.0 Crankcase Cover 1
45 9.803-906.0 O-Ring Ø1.78 x 14.00 1
46 8.707-262.0 Brass Plug G 3/8 1
47 9.803-202.0 Sight Glass G3/4 1
48 8.752-824.0 Cover Screw 5
* Part available in kit (See below)
