Landa VHP
REF PART NO. QTY DESCRIPTION NOTES
1 8.912-918.0 1 COVER, ELECTRICAL BOX
2 9.800-016.0 1 LABEL, DISCONNECT PWR SUPPLY
3 9.802-764.0 2 SCREW, 10/32" X 3/4", HEX
4 9.802-551.0 1 TRANSFORMER 240/480V - 120V (3-2000)
5 8.716-173.0 1 FUSE, PAPER 1 AMP 250V MIDGET (3-2000)
6 8.933-007.0 2 FUSE, 1 AMP 600V MIDGET (3-2000)
7 9.802-793.0 7 NUT, CAGE, 1/4" X 16 GA.
8 8.912-917.0 1 BOX, ELECTRICAL, VHW, BELT
- 9.802-762.0 1 SCREW, 10/32" X 1-1/4" NOT SHOWN
- 9.802-695.0 6 NUT, 10/32" KEPS NOT SHOWN
- - 10 NUT, 10/32" KEPS (ELECTRIC IGNITION)
- 9.800-040.0 1 LABEL, GROUND NOT SHOWN
9 8.912-919.0 1 COVER, PUMP & MOTOR, VHW BELT
10 8.912-888.0 1 HOLDER, WAND BRACKET, VHW/VHP
11 9.802-754.0 16 SCREW, 1/4" X 1/2", HH NC, WHIZ LOC
12 9.800-033.0 1 LABEL, WARNING HOT WATER
13 9.802-449.0 1 SWITCH, 3 PS, 115V-230V, 1 PH
14 8.912-916.0 1 PANEL, CONTROL, VHW, BELT
15 9.802-759.0 8 SCREW, 10/32" X 1/2" BHSOC BLK
- - 12 SCREW, 10/32" X 1/2" BHSOC BLK (ELECTRIC IGNITION)
16 9.802-776.0 5 NUT, 5/16", ESNA, NC
17 9.802-553.0 1 TRANSFORMER, 120/240 -24V .050 KVA
(ELECTRONIC
IGNITION OPTION)
18 9.802-514.0 3 STRAIN RELIEF, 1/2" LQ TITE
19 9.802-525.0 3 LOCKNUT, 1/2"
20 9.802-433.0 1 PLUG, GFCI, 240V, 20 AMP (3-2000)
- 9.802-431.0 1 CORD W/GFCI, 120V 20 AMPS (2-1500)
21 8.932-969.0 1 LABEL, WARNING, SERVICE CORD
22 9.802-772.0 2 SCREW, 10/32" X 1/4"
23 9.802-771.0 4 SCREW, 10/32" X 3/4"
24 9.802-146.0 1 SWIVEL, 1/2" MP X 3/4" GHF W/STRAINER
25 8.933-006.0 1 SWITCH FLOW MV 60, YELLOW
26 8.918-210.0 1 HOSE, 3/8" X 16", 2 WIRE, PRESSURE LOOP
27 8.750-299.0 1 UNLOADER, VRT 3, 8 GPM @4500 PSI
28 8.706-168.0 1 ELBOW, 3/8" MALE PIPE
29 9.802-695.0 8 NUT, 10/32” KEPS
30 9.802-127.0 1 NIPPLE, 1/2" JIC X 3/8" PIPE
31 9.802-036.0 1 NIPPLE, 1/2" JIC X 3/8" PIPE
32 9.802-767.0 4 SCREW, 3/8" X 3/4" WHIZ LOC
33 8.900-822.0 1 LABEL, VHP OPERATING INSTR.
34 8.706-984.0 1 ADAPTER, 1/2" X 1/2" PIPE
35 8.706-844.0 1 TEE 1/2" FEMALE, PIPE
36 8.706-797.0 1 NIPPLE, 1/2" HEX
