REF PART NO. QTY DESCRIPTION NOTES
37 9.802-128.0 1 NIPPLE, 1/2" JIC X 1/2" PIPE
38 8.707-254.0 1 PUMP PROTECTOR, 3/8" PTP
39 9.802-151.0 2 SWIVEL, 1/2" JIC FEM, PUSH-ON
40 9.802-259.0 12" HOSE, 1/2" PUSH-ON
41 8.754-710.0 1 MOTOR, 2 HP, 1 PH 3470 RPM, C-FACE (2-1500)
- 9.802-341.0 1 MOTOR, 5 HP 1 PH 3450 RPM C-FACE (3-2000)
- 9.800-032.0 1 LABEL, MOTOR OVERLOAD RESET, LEXAN NOT SHOWN
42 8.912-873.0 1 SUPPORT, PROPANE TANK, VHP
43 9.802-792.0 16 NUT, CAGE, 3/8" X 12 GA.
44 8.912-864.0 1 BRACE, LP BOTTLE, VHP
45 8.912-879.0 1 BRACKET, PROPANE TANK, VHP
46 8.912-882.0 1 STRAP, PROPANE TANK, R/H VHP
47 8.912-885.0 1 STRAP, PROPANE TANK, L/H VHP
48 8.719-063.0 1 KNOB, 3/8" - 16 X 1-1/2" VHP
49 9.804-029.0 1 PULLEY, AK64H (2-15024D)
- 9.802-380.0 1 PULLEY, BK80H (3-20024A)
50 8.715-517.0 1 PULLEY, BORE, AK21 X 5/8" (2-15024D)
- 9.802-377.0 1 PULLEY, BK32 (3-20024A)
- 9.803-897.0 1 BUSHING, H X 3/4
NOT SHOWN
(3-20024A)
51 9.802-402.0 1 BUSHING, HX24MM
52 9.804-026.0 1 BELT, AX31 (2-15024D)
- 9.802-413.0 1 BELT, BX32 (3-20024A)
53 8.717-749.0 1 REGULATOR, PROPANE, R532CFF
54 8.711-851.0 1 HOSE, 3/8" X 10', PROPANE ASSEMBLY
55 8.717-790.0 1 TANK, PROPANE 10.5 GAL. 30 LB. W/ GAUGE OPTIONAL
56 8.712-185.0 1 SWITCH, SNAP, 225 DR HI-LIMIT
57 8.706-851.0 1 CROSS, 1/2' FORGED, GALV. 3000WP
58 9.802-171.0 1 NIPPLE, 3/8" X 3/8" NPT ST MALE
59 9.802-013.0 1 NIPPLE, 1/2" X 2.5" GALV.
60 8.707-381.0 1 RUPTURE DISC ASSY, 8500#
61 8.706-167.0 1 ELBOW, 3/8" FPT, 90 DGR
62 9.802-259.0 30" HOSE, 1/2", PUSH-ON
63 9.802-043.0 1 ELBOW, 1/2" JIC X 1/2" FEM, 90 DGR
64 8.915-981.0 1 WRAP, OUTER COIL, VHW
- 9.800-021.0 1 LABEL, HOT WATER OUTLET NOT SHOWN
65 9.803-134.0 1 COIL, DURA, 14.5" DIA, SCH 80
66 8.719-968.0 1 HOLDER, WAND, VHW/VHP ZINC PLATED
67 9.803-029.0 1 TANK HEAD ASSEMBLY, 16" DIA X 8" STACK
68 9.800-006.0 2 LABEL, "HOT/CALIENTE" W/ARROWS
69 9.802-825.0 4 RETAINER CLIP
70 9.802-904.0 1 INSULATION, TANK HEAD 16" OD X 8" ID
71 8.912-899.0 1 HANDLE, VHW/VHP/MVP W/HNG
