30
Landa VHP
REF PART NO. QTY DESCRIPTION NOTES
72 8.912-871.0 1 PANEL, CHASSIS, FRONT/BACK
73 8.912-881.0 1 REFLECTOR, PILOT LIGHT, VHP/VHG
74 9.802-678.0 1 IGNITOR, PIEZO
75 8.912-875.0 1 SUPPORT, BURNER RING
76 9.802-778.0 4 NUT, WHIZ LOC 5/16 FLANGE
77 8.923-753.0 1 PUMP, LANDA LB3030R, 3.0@3000, 1650 RPM
78 8.912-920.0 1 RETAINER, TAKE-UP, PUMP
79 9.802-733.0 2 BOLT, 3/8" X 3-1/2" TAP
80 9.803-131.0 1 RAIL, PUMP COMBO
81 8.912-923.0 1 BASE, MAIN, VHP, BELT
82 8.718-054.0 1 BURNER RING, X-11 W/640-69 JET ORIFICES
83 9.802-064.0 1 GROMMET, RUBBER, NOZZLE HOLDER
84 9.802-463.0 1 FUSE, PAPER, BUSS FNM-1/2 250V MIDGET TD
(ELECTRONIC
IGNITION OPTION)
85 8.912-890.0 1 BRACKET, PILOT LIGHT, VHP/VHG
- 8.719-957.0 1
BRACKET, PILOT LIGHT, VNG-S(ELECTRIC
IGNITION)
86 8.718-150.0 1 PILOT, VHP
- 8.718-075.0 1 ORIFICE, PILOT, LP, SMALL NOT SHOWN
87 8.718-092.0 1 THERMOCOUPLE, 24" WHITE RODGERS
88 9.802-681.0 1 WIRE, 15" ASSEMBLY
- 9.802-682.0 1 TCB, GND NOT SHOWN
89 8.718-069.0 1 ELECTRODE, PIEZO ASSEMBLY
90 9.802-911.0 36" TUBING, ALUMINUM, 1/4" DEADSOFT
91 8.912-868.0 2 AXLE, 23", VHW
92 9.802-810.0 4 WASHER, 5/8", FLAT, SAE
93 9.800-031.0 1 LABEL, VHP PILOT LIGHT
94 8.754-186.0 4 QH WHEEL ASSY, 10" GRAY STEEL W/TUB
95 9.802-782.0 4 COLLAR, 5/8" BORE SHAFT
96 9.802-027.0 1 ELBOW, 3/4", BLACK, 90°
97 9.802-018.0 2 NIPPLE, 3/4" X 3". BLACK PIPE
98 9.802-049.0 1 UNION, 3/4", BLACK PIPE
99 8.718-045.0 1 VALVE, GAS, WR 36103A-410, 3/4"
- 9.803-616.0 1 VALVE, GAS
(ELEC. IGN.)
NOT SHOWN
- 9.803-618.0 1 LP,CONVERT KIT,ELEC IGN NOT SHOWN
100 8.912-858.0 2 AXLE, HOLDER ASSEMBLY VHW/VHP
101 8.706-108.0 1 NIPPLE, BLK, PIPE 3/4" X 3-1/2"
102 8.718-648.0 2 U-BOLT, 1/4" X 1-1/2" X 2-1/2" W/PLATE
103 8.706-108.0 1 NIPPLE, 3/4" X 3-1/2", BLACK PIPE
104 8.706-222.0 1 TEE, 3/4" NLK PIPE
105 9.802-018.0 1 NIPPLE, 3/4" X 3", BLACK PIPE
106 8.706-320.0 1 CAP, 3/4", BLACK PIPE
Landa VHP 2-1500 / 3-2000 Operator’s Manual 8.913-949.0 - T
