31Landa VHP 2-1500 / 3-2000 Operator’s Manual 8.913-949.0 - T
Landa VHP
REF PART NO. QTY DESCRIPTION NOTES
107 8.912-877.0 1 SUPPORT, GAS TRAIN, VHP/VHG
108 9.804-608.0 1 CAP, VINYL FKT (YELLOW)
109 8.912-930.0 1 ASSY, LEVER BRAKE
110 8.912-928.0 1 BRACKET, WHEEL BRAKE
111 8.718-980.0 12 WASHER, 5/16", FLAT, SAE
112 9.802-775.0 8 NUT, 1/4" FLANGE, WHIZ LOC
113 9.803-610.0 1 PILOT, IGNITOR (ELECTRIC IGNITION)
114 9.802-807.0 8 WASHER, 3/8", SAE, FLAT
115 8.718-785.0 1 SCREW, 3/8" X 3/8", SCKT
116 9.802-765.0 4 SCREW, 1/4" X 1/2" BH SOL CS
117 9.802-684.0 32 JET ORIFICE #69, DRILL TO #66
118 9.802-769.0 4 SCREW, 3/8" X 1-3/4" WHIZ LOC
119 9.802-781.0 11 NUT, 3/8" FLANGE WHIZ LOC
120 9.802-767.0 18 SCREW, 3/8" X 3/4" WHIZ LOC
121 8.932-965.0 2 LABEL, EXPOSED PULLEY
122 9.802-794.0 10 NUT, CAGE, 1/4" X 12 GA
123 8.706-168.0 1 ELBOW, 3/8" MALE PIPE
124 8.705-975.0 1 NIPPLE, 1/2" HEX STEEL
125 8.916-090.0 2 LABEL, LANDA
126 8.706-109.0 1 NIPPLE, 3/8" X 7", BLACK PIPE
127 8.933-007.0 2 FUSE, KTK-R1 600V MIDGET FUSE
(ELECTRONIC
IGNITION OPTION)
128 9.802-753.0 5 SCREW, 1/4" X 3/4", WHIZ LOC
129 8.900-300.0 1 LABEL, LANDA
130 8.932-963.0 1 LABEL, LIQUID PROPANE
131 8.900-829.0 1 LABEL, VHP, PROPANE TANK
132 8.912-894.0 1 BRACE, CHASSIS
133 9.803-562.0 1 CABLE, IGNITION, 48” (ELECTRIC IGNITION)
134 8.707-019.0 1 HOSE BARB, 1/2" BARB X 3/8" MPT, PUSH-ON
135 9.800-018.0 1 LABEL, TIPOVER HAZARD
136 9.800-049.0 1 LABEL, MANUFACTURER'S CLEANING SOLUTIONS
137 9.803-613.0 1 MODULE, IGNITION, ELECTRONIC
138 9.803-108.0 1 RETAINER RING, INSULATION
139 8.718-618.0 4 BOLT, 5/16" X 3/4" NC
140 9.802-518.0 1 STRAIN RELIEF 3/4
141 9.802-793.0 5 NUT, CAGE, 1/4" X 16 GA
142 8.706-294.0 1 BUSHING, 1/2 X 3/8 STEEL
143 8.755-957.0 1 STRAIN RELIEF, 3/4", 90DEG, BLK
144 9.802-427.0 2.75 FT CORD, SERV, 12/3, SEOOW, /FT
145 9.802-523.0 1 LOCKNUT, 3/4" CONDUIT
146 9.802-518.0 1 STRAIN RELIEF, STR, 3/4
To Next Page
