Landmann 42170 - Step 14: Regulator and Hose Assembly; Step 15: Door Installation

11
Assembly Instructions
F
EE
1414
Secure the regulator and hose assembly to the inside
right side panel (F) with one bolt (EE) as shown.
1515
K
H
K
A
L
Thread door bottom pin (L) into hole on bottom panel
(A). Align bottom hole on lower right corner of door (K)
to fit over door bottom pin (L). Carefully push down
spring pin on top right corner of door (K) and move
door so spring pin slides into the hole on cart frame (H).
