Lang DO36 - Parts List

PARTS LIST October 4, 2012, Rev A
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
1
1
Model: DO36 BAKE DECK OVEN
Fig No Part No Qty Description Application
1 2C-20103-02 37 SCRW SM PLT 10 X .5 PHLSL
2
N9-LA36-159
1 TOP LA OVEN S/S
DO36L (LOWER STACKED UNITS)
N9-LA36-159-1 DO36
3
2N-11050-25
2
ELE 36OVN 240V O/S 1.8KW DO36-240VM
2N-11050-29 ELMNT 36” OVEN 480V O/S DO36-440VM, DO36-480V, CLDO36L-440V
2N-11050-31 ELE 36”OVN 208V O/S 1.8KW DO36-208VM
2N-11050-33 ELMNT 36” OVEN 380V O/S 1.8KW DO36-380VM
4
2N-11050-26
2
ELE 36OVN 240V I/S 1.2KW DO36-240VM
2N-11050-30 ELMNT 36” OVEN 480V I/S DO36-440VM, DO36-480V, CLDO36L-440V
2N-11050-32 ELE 36”OVN 208V I/S 1.2KW DO36-208VM
2N-11050-34 ELMNT 36” OVEN I/S 1.2KW DO36-380VM
5 P9-50301-09 12 LONG ELEMENT CLIP S/S
6 P9-50301-10 12 SHORT ELEMENT CLIP
7 2C-20301-15 8 NUT HEX 10-32 PLTD
8 N9-LA36-109-1 1 CAPILLARY SHIELD
9 2P-70901-05 1 PLGBTNBLKPLSTC 3/4DP-750
10 2E-31200-02 1 LUG GROUNDING UL APPROVED
11 2C-20103-01 2 SCRW SM PLT 10X7/8 PHIL
12 2E-30500-07 1 TRM BLOCK 3PLELRGE 125AMP
13 N9-LA36-128 1 SWITCH DOOR ASSY
14 N9-LA36-193 1 DOOR ASSY A/L
15 2M-60301-43 1 DIE CAST PLT LANG SATIN
16 N9-LA36-184 1 DECK CHANNEL ASSY A/L
NI 2A-72500-06 4 LEG 5 1/2 W/BOLT DOWN ADJ CLDO36L-440V
NI 2B-50200-09 1 RACK 36 OVEN
NI 2B-50200-52 1 RACK 36 OVEN CRUISE LINE CLDO36L-440V
