Lang DO36 - Page 21

PARTS LIST October 4, 2012, Rev A
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
1
1
Star International Holdings, Inc. Company
DO36 36” BAKE DECK OVEN Details A & B
Fig No Part Number Qty Descr Application
1 N9-LA36-116 1 VENT PIPE ASSY
2 2T-30402-07 1 STAT ADJ 550o 48 C/T
3
2E-30304-W35
2
SWITCH - 3 POS ROTARY (mounted w/2 screws)
PS-60101-W3 KIT - 3 POS SWITCH REPL
4 2J-30801-01 1 TIMER MECHANICAL LONG
5 N9-LA36-130 1 CONTROL SLIDE ASSY
6 2C-20103-02 37 SCRW SM PLT 10 X .5 PHLSL
7 2C-20102-06 4 SCRW PHD ST 6-32X3/8
8 2C-20303-01 1 NUT HX SS 1/4-20
9 2R-70701-25 1 KNOB DAMPER BLACK PLAIN
10
Y9-70701-10
2
KNOB 3-HEAT 208-240V, BLACK
Y9-70701-10-2 KNOB 3-HEAT 208-240V, RED
11
Y9-70701-12
1
KNOB ASSYEMBLY 550°F, BLACK
Y9-70701-12-2 KNOB ASSYEMBLY 550°F, RED
12 Q9-70701-09 1 KNOB ASSY MANUAL TIMER
13
2J-31601-01
1
PILOT LT 250V 6LEAD BLK DO36-208VM
2J-31601-02 PILOT LT 480V 6LEAD BLK DO36-480V, DO36-480VM
14 2C-20101-77 2 SCRW MS PLT 6-32 X .25
15
2E-31800-01 2 CB 250V50A 1 POLE CRLNGSW DO36-208VM
2E-31800-04 1 CB 480V 50A 3-POLE DO36-480V, DO36-480VM, CLDO36L-440V
16 2C-20102-04 4 SCRW PHD ST 8-32X.5 PLTD
17 Q9-50312-81 1 BREAKER HOLDER
18 2C-20301-29 2 NUT HEX ACORN 1/4-20 S/S
19 2C-20204-02 2 WASHER SS 1/4 SPLIT LOCK
20 N9-LA36-142 1 DOOR INSIDE PANEL
21 2H-60106-31 1 INSULATION KIT DOOR
23 2A-50800-07 2 TENSION DISC STD OVEN
24 2A-LA36-145 2 DOOR RODS LA36
25 2A-LA36-146 2 DOOR PIPE LA36
26
2P-51001-01
1
SPRING OVN LH DOOR
2P-51001-02 SPRING OVN RH DOOR
27 2C-20105-04 2 SCREW SET 1/4-20X1/2
28 2C-20101-24 3 SCRW MS PLT 10-32 X .375
29 K9-60301-43-1
1 DIE CAST LOG + TINNERMAN
30 P9-50312-79 1 RANGE HANDLE
31 2R-50800-91 1 DOOR HANDLE
32 2C-20101-10 2 SCRW THD MS 1/4-20X2 1/4
33 Y9-50300-38 1 HANDLE MARINE MARINE APPLICATIONS
