Lanner NCA-5210 - Motherboard Layout

19
This layout shows the connectors and jumpers on the board, as a reference of the pin assignments and the
internal connectors.
PCIE5
JVGA
JCOM2
JUSB2
FAN1-4
J80Port
ATX2
JLCM
JSPIROM
JPMBus
JUSB1
JCOM1
ATX1
JUSB3
SATA3/4
OPMA
JLOM1
CASEOPEN
PCIE1
PCIE2
PCIE3
PCIE4
