Lanner NCA-5210 - Installing the CPU, Heatsink and Fan Duct

32
The motherboard supports 1 x 6
th
Generation Intel CPU (codenamed Skylake) with LGA1151 socket. Please
follow the steps below for installing the processor.
1. Locate and press the load lever.
2. Hold and drag the load lever outwards.
3. Drag the load lever out of the latch.
4. Move the load lever as shown in the image below.
5. Once the cover is opened, you can install the
CPU. Then, reverse the steps to securely lock the
CPU socket
