Lanner NCA-5210 - Installing Disk Drives

36
The system supports 1 x 3.5” or 2 x 2.5” SATA HDDs or SSDs as data storage. Please follow the steps below
for installation.
1. Remove the 4 screws that secure the disk drive tray.
2. Remove the tray and mount the hard disk on the tray using the provided disk screws.
3.5” SATA HDD/SSD
2.5” SATA HDD/SSD
SATA
Power Connector
SATA
Data Connector
SATA
Data Connector
SATA
Power Connector
